Disconnector Switch
Disconnector With Fuse Cutout
Insulation material
Porcelain or Polymer
Connector material
Copper or Aluminum
Standard
IEC 62271-102
Type
Outdoor
Function
Switch and fuse cutout
Application
Power line and substation
Rated voltage
10-36kv
Current rating
400-2000A
Details
The RH series has standard disconnector and it can attach fuse cutout as option. The option type has function as normal disconnector, meanwhile its special design can protect electric system from overload current with fuselink limit. Because of the integrate structure, total volume and weight reduced compared to separate disconnector and fuse cut. So it is easier to install on pole and save space.
